Transformer

MM 301

mala Cast Iron/S.G Iron Globe Valve Screwed

Specifications:

  • Screwed in Bonnet, Inside Screw, Rising Stem, Integral Seat with Renewable Disc
    Pressure Rating: PN- 10
    Screwed Female BSP Parallel Threads to BS:21

Hyd. Tested:

  • 15 Kgf / cm2 (200 PSIG)

Size Range:

  • 15mm (1/2 ") - 50mm( 2 " )
Note: Valve can be customized with LA & O/S Indicator on request*.
Download PDF

mala Cast Iron/S.G Iron Globe Valve Single Side Flanged

Specifications:

  • Screwed in Bonnet, Inside Screw, Rising Stem, Integral Seat with Renewable Disc
    Pressure Rating: PN- 10
    Inlet Flange as per BS: 10 Table-D (Undrilled)
    Outlet Screwed Female BSP Parallel Threads to BS:21

Hyd. Tested:

  • 15 Kgf / cm2 (200 PSIG)

Size Range:

  • 15mm (1/2 ") - 50mm( 2 " )
Note: Valve can be customized with LA & O/S Indicator on request*.
Download PDF
Transformer

MM 302

Transformer

MM 303

mala Cast Iron/S.G Iron Globe Valve Flanged

Specifications:

  • Screwed in Bonnet, Inside Screw, Rising Stem, Integral Seat with Renewable Disc
    Pressure Rating: PN- 10
    Flanges as per BS: 10 Table-D (Undrilled)

Hyd. Tested:

  • 15 Kgf / cm2 (200 PSIG)

Size Range:

  • 15mm (1/2 ") - 100mm ( 4 " )
Note: Valve can be customized with LA & O/S Indicator on request*.
Download PDF
